Roofing Lead Code 5 – 240mm

Characteristics of Code 5 Roofing Lead

Thickness and Weight:

• Thickness: 2.24mm
• Weight: 25.4 kg/m²

The thickness provides excellent durability and resistance to weathering, while the weight ensures it stays in place without requiring excessive fixings.

Material Properties:

• Malleability: Code 5 lead is malleable, allowing it to be easily shaped and formed around complex roof details.
• Durability: Lead is highly resistant to corrosion, ensuring a long lifespan even in harsh weather conditions.
• Recyclability: Lead is 100% recyclable, making it an environmentally friendly roofing material

Patination:

• Code 5 lead can develop a natural patina over time, which protects the lead from further oxidation and gives it a distinctive, aged appearance. Applying patination oil can enhance this process and prevent staining

Installation Considerations

Surface Preparation:

• Ensure the surface is clean, dry, and free from debris before applying the lead sheet.
• Use a suitable underlay, such as geotextile, to allow the lead to expand and contract without sticking to the roof surface.

Cutting and Shaping:

• Measure and cut the lead sheet accurately using tin snips or lead shears.
• Shape the lead using a lead dresser and bossing stick, ensuring it fits tightly against the roof features.

Fixing:

• Secure the lead sheet with copper or stainless steel nails, spaced at appropriate intervals to prevent movement.
• Dress the nail heads into the lead to avoid water ingress.

Joining:

• Overlap joints by at least 150mm and consider welding or soldering or welding for a continuous, watertight seal.

Patination:

• Apply patination oil to prevent white staining and ensure an even weathering process

Applications of Code 5 Roofing Lead (240mm Width)

Flashings:

• Used to create watertight seals around roof penetrations such as chimneys, vents, and skylights.
• The 240mm width is ideal for narrow flashings where a wider sheet would be unnecessary or cumbersome.

Gutters and Valleys:

• Suitable for lining narrow gutters and valleys to ensure effective water drainage and prevent leaks.
• The thickness of Code 5 provides sufficient durability to withstand the flow of rainwater and debris.

Abutments and Step Flashings:

• Used at the junctions where roof surfaces meet vertical walls.
• The flexibility of Code 5 lead allows it to be shaped around corners and steps in the roofline.

Roof Ridge and Hip Covers:

• Can be used to cover ridges and hips, providing a neat, watertight finish.
• The 240mm width is appropriate for narrower ridges and hips where larger sheets would be excessive.

Maintenance

Regular Inspections:

• Inspect the lead for signs of damage or wear, especially after severe weather conditions.
• Check for loose fixings and ensure joints remain watertight.

Cleaning:

• Clean the lead surface with a soft brush and mild soapy water to remove dirt and debris.

Repairs:

• Promptly address any minor splits or cracks using lead welding or patching techniques.
• Replace severely damaged sections to maintain the integrity of the roofing system.

Conclusion

Code 5 roofing lead (240mm width) is a versatile and durable material suitable for a range of roofing applications.

Its thickness and weight provide excellent durability, while its malleability allows for easy shaping and fitting around complex roof details. Further, by following best practices for installation and maintenance, roofing professionals can ensure that Code 5 lead provides a long-lasting, watertight, and aesthetically pleasing finish to any roof.
