Reclaimed Sandtoft Shire Concrete Pan Roof Tile

Reclaimed Concrete Single Pan Tile. - Image 2

Reclaimed Concrete Single Pan Tile. - Image 3

SKU: single pan Categories: Concrete Tiles, Pantiles, Reclaimed Roofing Materials Tags: concrete tiles, reclaimed concrete tile, reclaimed single pan, single pan, single pantiles

Reclaimed Concrete Single Pan Tile.

Name: Reclaimed Concrete Single Pan Tile.
SKU: single pan
Availability: InStock

The Reclaimed Co. Price:

£1.40 + Vat

214 in stock

Proctor Air ® Roof felt

Proctor Air roof felt is a unique three layer nonwoven, spunbonded, polypropylene breather membrane.
Used as a pitched roof underlay and is fixed beneath tiles and slates, and even hard metal roof coverings.
Provides a secondary barrier to the ingress of rain, wind and snow.
Collection available
Nationwide delivery service

Add for £120.00 + Vat

Treated Timber Battens 25mm X 50mm per m

John Brash Battens...

JB Red quality roofing battens, 25mm x 50mm treated softwood battens. Such battens are suitable for all roofing applications.

Also known as Lath

For fixing roof tiles, slates, sheets, shingles, cladding and other roofing and facade applications.

Price depicted is per linear metre.

Add for £0.80 + Vat

Paslode Roofing Nails 63mm X 3.1mm Galvanised

Paslode roofing nails, used for fixing battens using a nail gun.
Nail gun roofing nails to comply with BS5534.
63mm x 3.1mm galvanised ring shank nails.
Provides a secure fixing to roof structure.
Complete with 2200 nails and 2 gas canisters, enough for the whole pack.

Add for £82.00 + Vat

🚚 Delivery
🏪 Collection

Delivery calculated at checkout and can be delivered nationwide by pallet/courier or locally by our own fleet

Your nearest store:

York

Sutton Road, Wigginton, YO32 2RB

Directions

Find more stock

need assistance?

Request Video

Reclaimed Sandtoft Shire concrete pan roof tiles in orange.
featuring a durable interlocking single pan profile.
Approx 420x330mm.
ideal for roof repairs.
extensions, and full re-roofs.

+Product Info

Description

Reclaimed Sandtoft Shire Concrete Pan Roof Tiles – orange

Reclaimed Sandtoft Shire Concrete Pan Roof Tiles feature a traditional single pan profile combined with durable concrete construction. Carefully salvaged from UK roofs, these tiles provide a sustainable and cost-effective solution for refurbishment, extensions, and new roofing projects. Their simple pan design offers a clean, classic appearance suited to a wide range of properties.

Reclaimed Sandtoft Shire Concrete Pan Tile Technical Spec

Material: Concrete (reclaimed)
Colour: orange / terracotta tone (weathered)
Tile size: Approx. 420 x 330–334 mm
Hanging length: ~400 mm
Profile: Single pan (interlocking)
Cover width: ~300 mm
Roof coverage: ~9.5 – 10 tiles per m² depending on headlap
Minimum roof pitch: 15° (smooth finish) / 30° (granular finish)
Maximum roof pitch: 90°
Headlap: 75 mm minimum
Batten spacing: ~300 – 345 mm
Weight per tile: ~4.0 – 4.5 kg
Weight as laid: ~43 – 48 kg per m²
Tiles per pallet: ~200 – 216
Fixings: Ring shank aluminium alloy nails, typically 45–65 x 3.35–3.75 mm (BS 5534 compliant)

These reclaimed Sandtoft Shire concrete pan tiles are suitable for new builds, roof repairs, extensions, and heritage-style projects. The interlocking single pan profile allows for efficient installation while maintaining a traditional roof appearance.

Reclaimed Roofing Expertise

Whether restoring a period property or sourcing sustainable roofing materials, our reclaimed Sandtoft Shire tiles offer durability, character, and value. All tiles are carefully inspected, sorted, and cleaned to ensure quality and usability.

Explore our full range of reclaimed concrete roof tiles here. Learn more about our sourcing standards and reclaimed materials on our About Us – The Reclaimed Connection page.

Do you have any to sell?

Have similar reclaimed roofing materials available? List them on our specialist marketplace at The Reclaimed Company and connect with buyers looking for genuine reclaimed building materials. Your first listing is free!

Additional information

Weight	4 kg
Dimensions	38 × 21 × 5 cm

Slate Calculator

Slating Headlap

Lap

Expandable Headlap Info

Choosing Headlap

Definition: The vertical overlap between successive rows of tiles to prevent water ingress.

Factors to consider:

Roof pitch: Shallower pitches (< 30°) need 75–100 mm; steeper (> 45°) can use 50 mm.
Climate & exposure: Wind-driven rain or heavy rainfall zones benefit from more headlap.
Tile profile: Deeper tiles may require extra overlap to seal correctly.

Rule of thumb:

Standard (30–45°): 50–75 mm
Low (< 30°): 75–100 mm
High (> 45°): 50 mm

Slate Size / Type

Slate 50mm Lap

Selecting Tile Size

Coverage per tile: Larger tiles cover more area but are heavier, affecting handling and substrate load.

Aesthetic scale: Big tiles suit modern, minimal lines on large roofs; smaller tiles give more texture and a traditional look.

Structural limits: Check rafters and battens can support the chosen tile’s weight and fixing centres.

Installation speed vs. waste: Larger tiles lay faster but may require more cutting at edges, increasing waste. Smaller tiles take longer but can reduce off-cuts.

Compatibility: Ensure the tile size works with your chosen headlap & side-lap for correct coverage per m².

By balancing pitch, weather, substrate capacity and appearance, you’ll pick the optimal tile size for performance and style.

Slate 75mm Lap

Selecting Tile Size

Coverage per tile: Larger tiles cover more area but are heavier, affecting handling and substrate load.

Aesthetic scale: Big tiles suit modern, minimal lines on large roofs; smaller tiles give more texture and a traditional look.

Structural limits: Check rafters and battens can support the chosen tile’s weight and fixing centres.

Installation speed vs. waste: Larger tiles lay faster but may require more cutting at edges, increasing waste. Smaller tiles take longer but can reduce off-cuts.

Compatibility: Ensure the tile size works with your chosen headlap & side-lap for correct coverage per m².

By balancing pitch, weather, substrate capacity and appearance, you’ll pick the optimal tile size for performance and style.

Slate 100mm Lap

Selecting Tile Size

Coverage per tile: Larger tiles cover more area but are heavier, affecting handling and substrate load.

Aesthetic scale: Big tiles suit modern, minimal lines on large roofs; smaller tiles give more texture and a traditional look.

Structural limits: Check rafters and battens can support the chosen tile’s weight and fixing centres.

Installation speed vs. waste: Larger tiles lay faster but may require more cutting at edges, increasing waste. Smaller tiles take longer but can reduce off-cuts.

Compatibility: Ensure the tile size works with your chosen headlap & side-lap for correct coverage per m².

By balancing pitch, weather, substrate capacity and appearance, you’ll pick the optimal tile size for performance and style.

Slates Per m2

Expandable Slates per m² Info

Calculating Slates per m²

Definition: Number of slates needed to cover one square metre.

Formula: 1 000 000 mm² ÷ (effective width × effective height)

Where:

Effective width = tile width – side lap
Effective height = tile height – head lap

Example: 610 mm × 355 mm tile, 20 mm side lap, 75 mm head lap:

Effective width: 610 − 20 = 590 mm
Effective height: 355 − 75 = 280 mm
Area per slate: 590 × 280 = 165 200 mm²
Slates per m²: 1 000 000 ÷ 165 200 ≈ 6.05

Adjust your headlap and sidelap values for precise coverage calculations.

Slate Required(Required)

Measure Your Roof Area

Determining Your Roof’s Area (m²) Accurately measuring your roof is essential to estimate how much slate you’ll need. Follow these steps: Measure the rafter length Runs from the gutter up to the ridge line.

Width (m)

Length (m)

Total Mtr²

Total Slates Required

Copper Nails Total KG

Expandable Copper Nails Info

Copper Nails for Slating: Overview & Specs

Why use copper nails?

Corrosion resistance: Forms a protective patina to prevent rust and staining.
Superior durability: Lasts for decades without needing replacement.
Optimal flexibility: Absorbs roof movement without cracking or shearing.
Aesthetic harmony: Weathers to a warm patina that complements natural slate.
Chemical compatibility: No galvanic reaction with slate or lead flashings.

Packaging & usage:
